Driving Type

Left / Right Hand Driving

Cabin

1880 Cabin ( Berth can be optional)

2080 Cabin ( Berth can be optional)

Engine

Power

85-116HP

120HP

140-160HP

Diesel  EURO II, IV, V

Transmission

MANUAL, 5F, 6F

Steering

hydraulic steering with power assistance

Axle

Design and produce by SINOTRUK

Oil tank

80/120L

Tyres

7.00R16

7.50R16/8.25R16

8.25R20/9.0R20

Front/ Rear  Axle

2.0+4.2

2.4+7.2

3.6+10.5

Wheelbase

3360

3800/4200/4500

4700/5200

tank

Tank Material

Carbon steel /Stainless steel

Medium

Diesel or gasoline

Capacity

1-5 m³

6-10m³

11-15 m³

Pump power

5.4kw

11.7kw

Refueling flow

70L/min

Refueling hose

10-50m

Discharge Hose

non-transparent hose, two pieces.three meters

Security configuration

Explosion-proof cover ,aluminum made

Bottom valve

Anti-Static device(Copper grounding joint, static conductive reel , static conductive rubber belt)

Fire-extinguisher(dry powder type, 2 pieces)
