Driving Type

Left / Right Hand Driving

Cabin

1880 Cabin

2080 Cabin

Engine

Power

95-120HP

140/160HP

Emission

Diesel  EURO II, IV, V

Transmission

MANUAL, 5F, 6F

Steering

hydraulic steering with power assistance

Frame

Reinforced frame

Front  Axle

2.0-2.4

2.4-3.6

Rear  Axle

3.5-4.2

7.2-10.5

Wheelbase

3360/3800/4200

4500/4700/5200

Tyres

7.00R16/7.50R16

8.25R16/8.25R20/9.0R20

Cargo

Loading Weight

4-8 Tonnes

8-15 Tonnes

Cargo Length (mm)

3200-4150

4200-5800

Cargo Width (mm)

2050

2150/2300

Cargo Body

Floor 2.5 mm Side 1.5 mm

Crane-straight arm

Max lifting capacity kg

3ton

4ton

5ton

Max lifting moment T.M

6.72

10

12.5

Rotation angel

360°

Max working radius

7.56m

9.42m

11m

Oil tank capacity

30L

60L

90L
